D SERIES D SERIES
D07
D07
Max. Power Output (kw/rpm)
0
0r/min
Maximum Speed (km/h)
0
Max. Torque (Nm/rpm)
0
0r/min
Wheelbase (mm)
0
Max. Power Output (kw/rpm)
0
0r/min
Maximum Speed (km/h)
0
Max. Torque (Nm/rpm)
0
0r/min
Wheelbase (mm)
0
Max. Power Output (kw/rpm)
0
0r/min
Maximum Speed (km/h)
0
Max. Torque (Nm/rpm)
0
0r/min
Wheelbase (mm)
0
SPECIFICATIONS
Engine
Engine Type
Liquid-cooled single-cylinder 4 Valve Auto start-stop Silence start
Engine Displacement
174CC
Max. Power Output
13.6 KW / 8500 rpm
Max. Torque
17.2 Nm / 6500 rpm
Emission Standards
Euro V
Chassis,Dimensions and Weight
Length x Width x Height(mm)
2005 x775x1200
Seat Height(mm)
770
Wheelbase(mm)
1374
Kerb Weight (kg)
150/140
Wheels, Suspension and Brakes
Front brake
Single disc Φ240mm ABS(with TCS)
Rear brake
Single disc Φ220mm ABS(with TCS)
Tyres (Front/Rear)
Fr:110/70-14 Rr:130/70-13
Suspension Front
Telescopic fork
Suspension Rear
Twin shocks
Engine
Engine Type
Liquid-cooled single-cylinder 4 Valve Auto start-stop Silence start
Engine Displacement
149.6CC
Max. Power Output
11.5 KW / 8500 rpm
Max. Torque
14.7 Nm / 6500 rpm
Emission Standards
Euro V
Chassis,Dimensions and Weight
Length x Width x Height(mm)
2005 x775x1200
Seat Height(mm)
790/780
Wheelbase(mm)
1374
Kerb Weight (kg)
150/140
Wheels, Suspension and Brakes
Front brake
Single disc Φ240mm with CBS or ABS+TCS
Rear brake
Single disc Φ220mm with CBS or ABS+TCS
Tyres (Front/Rear)
Fr:110/70-14 Rr:130/70-13
Suspension Front
Telescopic fork
Suspension Rear
Twin shocks
Engine
Engine Type
OHC,Liquid-cooled single-cylinder 2 VALVE
Engine Displacement
124.9 CC
Max. Power Output
8.3 KW / 8500 rpm
Max. Torque
11.2 Nm / 6500 rpm
Emission Standards
Euro V+
Chassis,Dimensions and Weight
Length x Width x Height(mm)
2005 x775x1200
Seat Height(mm)
790/780
Wheelbase(mm)
1374
Kerb Weight (kg)
150/140
Wheels, Suspension and Brakes
Front brake
Single disc Φ240mm with CBS or ABS+TCS
Rear brake
Single disc Φ220mm with CBS or ABS+TCS
Tyres (Front/Rear)
Fr:110/70-14 Rr:130/70-13
Suspension Front
Telescopic fork
Suspension Rear
Twin shocks
