TARO | Zhejiang Leqi Vehicle Co.,Ltd

D SERIES

D SERIES

D03-XADV

D03-XADV

180 LC 150 LC 125 AC 125 LC

Max. Power Output (kw/rpm)

0

0r/min

Maximum Speed (km/h)

0

Max. Torque (Nm/rpm)

0

0r/min

Wheelbase (mm)

0

最大功率输出 (kw/rpm)

0

0r/min

最高时速 (km/h)

0

最大扭矩 (Nm/rpm)

0

0r/min

轴距 (mm)

0

Max. Power Output (kw/rpm)

0

0r/min

Maximum Speed (km/h)

0

Max. Torque (Nm/rpm)

0

0r/min

Wheelbase (mm)

0

Max. Power Output (kw/rpm)

0

0r/min

Maximum Speed (km/h)

0

Max. Torque (Nm/rpm)

0

0r/min

Wheelbase (mm)

0

ADVANTAGES

SPECIFICATIONS

ADV-X 180 LC

ADV-X 150 LC

ADV-X 125 AC

ADV-X 125 LC

Engine

Engine Type

Liquid-cooled single-cylinder 4 stroke,Auto start-stop Silence start 4 VALVE

Engine Displacement

174CC

Max. Power Output

13.5 KW / 8500 rpm

Max. Torque

17.2 Nm / 6500 rpm

Emission Standards

Chassis,Dimensions and Weight

Length x Width x Height (mm)

1945 x778x1235 mm

Seat Height(mm)

770

Wheelbase(mm)

1374

Kerb Weight (kg)

150/140

Wheels, Suspension and Brakes

Front brake

Single disc Φ240mm ABS(with TCS)

Rear brake

Single disc Φ220mm ABS(with TCS)

Tyres (Front/Rear)

Fr:110/70-14 Rr:130/70-13

Suspension Front

Telescopic fork

Suspension Rear

Twin shocks

发动机

发动机类型

液冷单缸四气门发动机，自动启停功能，静音启动

发动机排量

149.6CC

最大功率输出

11.5 KW / 8500 rpm

最大扭矩

14.5 Nm / 6500 rpm

排放标准

底盘、尺寸和重量

长x宽x高(mm)

1945 x778x1235 mm

座椅高度(mm)

790/780

轴距(mm)

1374

整备质量 (kg)

150/140

车轮、悬挂和制动系统

前制动器

单盘 Φ240mm，配备CBS或ABS+TCS系统

后制动器

单盘 Φ220mm，配备CBS或ABS+TCS系统

轮胎(前/后)

前轮：110/70-14 后轮：130/70-13

前悬挂

伸缩式叉臂

后悬挂

双重冲击

Engine

Engine Type

AIR-cooled single-cylinder 4 stroke

Engine Displacement

123.9CC

Max. Power Output

6.8 KW / 7500 rpm

Max. Torque

9.8 Nm / 6000 rpm

Emission Standards

Euro V+

Chassis,Dimensions and Weight

Length x Width x Height (mm)

1945 x778x1235 mm

Seat Height(mm)

790/780

Wheelbase(mm)

1374

Kerb Weight (kg)

150/140

Wheels, Suspension and Brakes

Front brake

Single disc Φ240mm with CBS

Rear brake

Single disc Φ220mm with CBS

Tyres (Front/Rear)

Fr:90/90-14 Rr:120/70-13

Suspension Front

Telescopic fork

Suspension Rear

Twin shocks

Engine

Engine Type

Liquid-cooled single-cylinder 4 stroke,Auto start-stop Silence start

Engine Displacement

124.9CC

Max. Power Output

8.3 KW / 8500 rpm

Max. Torque

11.2 Nm / 6500 rpm

Emission Standards

Euro V+

Chassis,Dimensions and Weight

Length x Width x Height (mm)

1945 x778x1235 mm

Seat Height(mm)

790/780

Wheelbase(mm)

1374

Kerb Weight (kg)

150/140

Wheels, Suspension and Brakes

Front brake

Single disc Φ240mm with CBS or ABS+TCS

Rear brake

Single disc Φ220mm with CBS or ABS+TCS

Tyres (Front/Rear)

Fr:100/80-16 Rr:120/70-14

Suspension Front

Telescopic fork

Suspension Rear

Twin shocks
